XT-QHigh Definition Printing Polishing Drying Die-cutting Machine


Main Technical parameter:


900×2000 1200×2000 1200×2400 1400×2000 1400×2400
1 Inboard width size mm 2400 2400 2800 2400 2800
2  Max.paper size mm 950x2200 1270x2200 1270x2600 1470x2200 1470x2600
3  Max.printing size mm 900x2000 1200x2000 1200x2400 1400x2000 1400x2400
4  Skip feeding size mm 1150x2000 1450x2000 1450x2400 1650x2000 1650x2400
5 Min finish size mm 300x640 320x640 320x640 380x720 380x720
6  Thickness of printing plate mm 7.2 7.2 7.2 7.2 7.2
7  Max.speed P/min 220 180 180 160 160
8  Topping precision mm 6 colors±0.3 6 colors±0.3 6 colors±0.3 6 colors±0.3 6 colors±0.3
9  Slotting precision mm ±1 ±1 ±1 ±1 ±1
10  Max.slotting depth mm 200 300 300 350 350
Function and Characteristics:
High precision, six colors 0.3mm printing accuracy; High wire, 140LPI printing wire; High efficiency, high printing, drying, coating, drying again, slotting, die cutting, waste cleaning, piling, counting whole complete; Low consumption, multi-stage risk control, multi-stage temperature control, frequency conversion with servo, saving electricity.
Whole machine electric parts was choice the international famous brand , good quality and steady.
Complete machine baffle and important parts was used the temper for decrease the metal internal force, and that parts was made by high precision process center and grinded by digit-controlled grinder.
All the transmission axle and roller are made by the high-quality steel, temper, and dynamic balance; plated with rigid chrome and grinded surface.
All the transmission gear was used the 20CrMnTi  alloy steel, which is grinded after heat-treatment, and it was made by rubbing , it still maintains the high topping precision.
The whole machine undergoes the spray lubrication , intuitionist show setting ,setting the double oil pipe balance system
Whole machine working interval adjustment, free-spanner self-lock worm wheel and worm device , fast and convenient.
Can choice servo motor free pressure or lead edge feeder suction
Setting the ink alarm device ,real-time monitoring of the work status of the ink supply system.
One-button antomatic pre-stick printing plate, computer can adjustment every printing unit printing plate to center of the cardboard according to the width of the cardboard, reduce waste cardboard when adjustment the machine.
